Accurate gas measurement results with the GT, GTS, GTX, and AccuTest Turbine Gas Meters

Turbine meters from Honeywell Elster are designed to accurately measure natural gas, air, nitrogen, carbon dioxide, propane vapor, and other non-corrosive gases. The meters are recommended to meet operational requirements for large volume commercial and industrial uses.

The velocity of the gas stream passing through the meter is measured using rotor blades that result in a rotational speed proportionate to the flow rate. Characteristics of the turbine meter increase meter performance by minimizing minor flow distortions to deliver accurate gas measurement results.



G Series Turbine Meter Features

  • Common gear train for 3”, 4”, 6”, and 8” meter sizes reducing spare parts inventory
  • Easy maintenance with interchangeable pre-calibrated measurement cartridges
  • High efficiency inlet Flo-Guide conditioners
  • Several volume registration outputs

GT, GTS, GTX, and Accutest Turbine Meters Specifications

Technical data
Value
Sizes
3” to 12”
Pressure Range
175 PSIG to 1480 PSIG
Temperature Range
-40°C to 60°C (-40°F to 140°F)
Body Materials
Cast aluminum, cast steel, or steel depending on pressure rating
Units of Measurement
English or Metric
