Remote communications from your measurement instruments in hazardous locations with the Cloud Link Modem

Let's talk

The Honeywell Cloud Link TM is a 4G/LTE cellular device assembly intended to process serial data originating from any source, including a Honeywell Electronic Volume Corrector or Data Logger.



Cloud Link Features

  • 4G/LTE transparent serial modem
  • Operates with major carriers in North America
  • 1 digital input
  • 5 years battery life with 1 battery + 1 call per day
  • 8 years battery life with 2 batteries + 1 call per day

Cloud Link 4G LTE Link Modem Specifications

Technical data
Value
Wireless Specifications
LTE: Five band, 700 (Bd13)/700 (Bd17)/850 (Bd5)/AWS (Bd4)/1900MHz (Bd2)
UMTS/HSPA+: Triple band, 850 (BdV)/AWS (BdIV)/1900MHz (BdII)
GSM/GPRS/EDGE: Quad band, 850/900/1800/1900MHz
Bluetooth Low Energy: v.4.0 (2402-2480MHz)
Environmental Conditions
Temperature: -25°C to +65°C
Humidity: 0%-95% RH, non-condensing
Power Supply Options
Battery connector: 3.4Vdc minimum, 3.6Vdc nominal, 3.9Vdc maximum, 2A peak
External power: 4.8Vdc minimum, 30Vdc maximum, 2A peak
Input/Outputs/Interfaces
Digital input: pulse counter, alarm input (typical door tamper alarm), call trigger
RS232/485
Magnetic switch: wakes the unit up by swiping a magnet and forces a call
Security
SSL/TLS 1.2 version security
Ordering Code: 22-3018-KIT
Certifications
PTCRB
Verison, AT&T, Rogers
CSA C/US Class-1, Div-2, Group A, B, C and D
FCC
Industry Canada
Warranty
4 year standard warranty
