Perfect accuracy & safety with the FE commercial regulator

The FE is a double-stage self-operated pressure regulator for residential & commercial applications and it is suitable for use with gaseous fluids such as natural gas, LPG and non-corrosive gases. These regulators are designed to be installed directly on utility meters or on riser mains for diaphragm or rotary meters.

The FE can be installed in any position. The discharge of the internal relief valve can be conveyed outside in case of installation. The FE regulator is CSA approved and Measurement Canada approved for PFM sets.

FE Pressure Regulator Specifications

Technical data
Value
Accuracy Class
Up to 5%
Closing Pressure Class SG
Up to 10%
Design Pressure
125 PSI
Design Temperature
-30°C +60°C
Outlet Pressure Range of Wd
BP: 5″WC – 2.6 PSI / TR: 2.6 PSI – 7.25 PSI
Range of Inlet Pressure bpu
125 PSI
Threaded Connections
See catalog
